300W 20A DC-DC Buck Converter Step Down Module with Current Limiting Range of 0.2-20A

Name: 300W 20A DCDC Buck Converter Step Down Module with Current Limiting Range of 0220A
Brand: creatall
Price: 3.06 USD

Wholesale 300W 20A DC-DC Buck Converter Step Down Module with Current Limiting Range of 0.2-20A from china suppliers

Network : standard

Customized support : Software reengineering

Place of Origin : Guangdong, China

Brand Name : creatall

Model Number : 300w 20a

Type : DC/DC Converters

Output Type : standard

Output Current : 20a, Maximum 20A

Output Frequency : standard

Size : 60 x 53 x 27mm

Input Voltage : DC 6-40V

Output Voltage : DC1.2-35V

Adjustable Resistance : 100K

Current Limiting Range : 0.2-20A

Minimum Voltage Difference : 3V

Operating Frequency : 150KHZ

Conversion Efficiency : Up To About 96%

Output Ripple : 50mV

MOQ : 25 pieces

Price : $3.06/pieces 25-100 pieces

Contact Now

Products Description

Description:
This Product Uses Synchronous Rectification Technology, Which Is a New Technology That Uses Special Power With Extremely Low
On-State Resistance To Replace Rectifier Diodes To Reduce Rectification Losses. Reduce The Heat Of The Power Supply Itself.

Specification:
1. Input Voltage: DC 6-40V
2. Output Voltage: DC1.2-35V
3. Output Current: Maximum 20A
4. Adjustable Resistance: 100K
5. Current Limiting Range: 0.2-20A
6. Minimum Voltage Difference: 3V
7. Operating Frequency: 150KHZ
8. Conversion Efficiency: Up To About 96%
9. Output Ripple: 50mV
10. Operating Temperature: -10~75°C

Package Including: 1PC*Buck Converter
